| Color/Finish | Body | Color | Black | Black | Svart |
|---|---|---|---|---|---|
| Size/Weight | Dimensions | Width | 1,234 mm (48-9/16") | 1,017 mm (40-1/16") | 1 017 mm (40-1/16") |
| Height | 151 mm (5-15/16") | 139 mm (5-1/2") | 139 mm (5-1/2") | ||
| Depth | 456 mm (17-15/16") | 431 mm (17") | 431 mm (17") | ||
| Weight | Weight | 14.2 kg (31 lb, 5 oz) | 11.6 kg (25 lb, 9 oz) | 11.6 kg (25 lb, 9 oz) | |
| Packing Box | Width | 1,460 mm (57-1/2") | 1,174 mm (46-3/16") | 1174 mm (46-3/16") | |
| Height | 270 mm (10-5/8") | 246 mm (9-11/16") | 246 mm (9-11/16") | ||
| Depth | 540 mm (21-1/4") | 511 mm (20-1/8") | 511 mm (20-1/8") | ||
| Control Interface | Keyboard | Number of Keys | 76 | 61 | 61 |
| Type | Organ (FSX), Initial Touch/Aftertouch | Organ (FSB), Initial Touch | Orgel (FSB), Initial Touch | ||
| Touch Response | Normal, Easy1, Easy2, Soft1, Soft2, Hard1, Hard2 | Normal, Soft1, Soft2, Hard1, Hard2 | Normal, Soft1, Soft2, Hard1, Hard2 | ||
| Other Controllers | Joystick | Yes (Assignable) | Yes (Assignable) | Ja (kan tilpasses) | |
| Control Knobs | 6 (Assignable, with LED gauge) | 2 (Assignable) | 2 (kan tilpasses) | ||
| Sliders | 9 Live Control sliders (Assignable, with LED gauge), Cross Fader | - | - | ||
| Art. Switches | 3 | - | - | ||
| Pitch Bend | - | - | - | ||
| Modulation | - | - | - | ||
| Assignable Buttons | 9 (A–F, 1–3) | 8 (A–F, 1–2) | 8 (A–F, 1–2) | ||
| Display | Type | Main Display: TFT Color Wide VGA LCD | Sub Display: VA (Live Control view) | TFT Color Wide VGA LCD | TFT-farge Wide VGA LCD | |
| Size | Main Display : 800 x 480 dots (9 inch) | Sub Display: 512 x 48 dots | 800 x 480 dots (7 inch) | 800 x 480 piksler (7 tommer) | ||
| Touch Screen | Main Display : Yes | Yes | Ja | ||
| Color | Yes | Yes | Ja | ||
| Language | Main Display: English, German, French, Spanish, Italian | Sub Display: English | English, German, French, Spanish, Italian, Chinese | Engelsk, Tysk, Fransk, Spansk, Italiensk, Kinesisk | ||
| Panel | Language | English | English, Chinese | Engelsk, Kinesisk | |
| Voices | Tone Generation | Tone Generating Technology | FM, AWM Stereo Sampling, AEM technology | AWM Stereo Sampling, AEM technology | AWM Stereo Sampling |
| Polyphony | Number of Polyphony (Max.) | 384 (128 for Preset AWM Voices + 128 for Expansion AWM Voices + 128 for FM Voices) | 128 | 128 | |
| Preset | Number of Voices | 1,991 Voices + 75 Drum/SFX Kits + 480 XG Voices | 1,587 Voices + 63 Drum/SFX Kits + 480 XG Voices | 1 377 stemmer + 56 tromme-/SFX-sett + 480 XG-stemmer | |
| Featured Voices | 106 S.Articulation2, 437 S.Articulation, 141 FM, 40 Sweet!, 81 Cool!, 188 Live!, 25 OrganFlutes, 123 MegaVoice, 11 Ambient Drums/SFX, 11 Revo Drums/SFX | 12 S.Articulation2, 15 S.Articulation+, 340 S.Articulation, 55 OrganFlutes, 82 MegaVoice, 31 Sweet!, 87 Cool!, 149 Live! | 9 S.Articulation+, 252 S.Articulation, 55 OrganFlutes, 54 MegaVoice, 31 Sweet!, 87 Cool!, 131 Live! | ||
| Compatibility | XG, GM, GM2 (for Song Playback) | XG, GM, GM2 (for Song Playback) | XG, GM, GM2 (for sangavspilling) | ||
| Expandability | Expansion Voice | Yes (approx. 3 GB) | Yes (approx. 2 GB) | Ja (ca. 1 GB) | |
| Editing | Voice Set | Voice Set | Stemmesett | ||
| Part | Right 1, Right 2, Right 3, Left | Right1, Right2, Right3, Left | Høyre1, høyre2, høyre3, venstre | ||
| Effects | Types | Reverb | 85 Preset + 30 User | 59 Preset + 30 User | 59 forhåndsinnstillinger + 30 bruker |
| Chorus | 107 Preset + 30 User | 107 Preset + 30 User | 106 forhåndsinnstillinger + 30 bruker | ||
| DSP | 363 Preset (with VCM) + 30 User | 358 Preset (with VCM) + 30 User | 322 forhåndsinnstillinger + 30 Bruker | ||
| Insertion Effect | 1-28: 363 Preset (with VCM) + 30 User | Block 1-13: 358 Preset (with VCM) + 30 User | Blokk 1-9: 322 forhåndsinnstilte + 30 brukere | ||
| Master Compressor | 5 Preset + 30 User | 5 Preset + 30 User | 5 forhåndsinnstillinger + 30 bruker | ||
| Master EQ | 9 Preset + 30 User | 5 Preset + 30 User | 5 forhåndsinnstillinger + 30 bruker | ||
| Part EQ | 28 Parts | 28 Parts | 28 deler | ||
| Others | Mic effects: Noise Gate, Compressor, 3 Band EQ, Vocal Effect: 23 | Mic/Guitar Effects: Noise Gate, Compressor, 3 Band EQ, Vocal Effect: 23 | Mic-/gitar-effekter: Støygate, kompressor, 3-bånds EQ | ||
| Arpeggio | Yes | Yes | Ja | ||
| Vocal Harmony | Number of Presets | Vocal Harmony: 54, Synth Vocoder: 20 | Vocal Harmony: 54, Synth Vocoder: 20 | - | |
| Number of User Settings | 60 *The number is the total of Vocal Harmony and Synth Vocoder | 60 *The number is the total of Vocal Harmony and Synth Vocoder | - | ||
| Accompaniment Styles | Preset | Number of Preset Styles | 800 | 575 | 450 |
| Featured Styles | 720 Pro Styles, 69 Session Styles, 11 Free Play Styles | 520 Pro Styles, 49 Session Styles, 6 Free Play Styles | 410 Pro-stiler, 37 Session-stiler, 3 frispill-siler | ||
| Fingering | Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard | Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard, Smart Chord | Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard, Smart Chord | ||
| Style Control | INTRO × 3, MAIN VARIATION × 4, FILL × 4, BREAK, ENDING × 3 | INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3 | INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3 | ||
| Other Features | One Touch Setting (OTS) | 4 for each Style | 4 for each Style | 4 for hver stil | |
| Chord Looper | Yes | Yes | Ja | ||
| Style Section Reset | Yes | Yes | Ja | ||
| Style Dynamics Control | Yes (with Fader) | Yes (with knobs / pedal) | Ja (med knotter/pedal) | ||
| Style Section Change Timing | Yes | Yes | Ja | ||
| Style Section Time Signature | Yes | Yes | Ja | ||
| Expandability | Expansion Style | Yes (Internal Memory) | Yes (Internal Memory) | Ja (internt minne) | |
| Expansion Audio Style | Yes (Internal Memory) | Yes (Internal Memory) | - | ||
| Compatibility | Style File Format (SFF), Style File Format GE (SFF GE) | Style File Format (SFF), Style File Format GE (SFF GE) | Style File Format (SFF), Style File Format GE (SFF GE) | ||
| Akkompagnementsstiler | Andre funksjoner | Unison og aksent | - | - | - |
| Songs | Preset | Number of Preset Songs | 9 Demo Songs, 1 Preset Song | 1 Demo Song, 2 Preset Songs | 1 demosang, 2 forhåndsinnstilte sanger |
| Recording | Number of Songs | Unlimited (depends on the drive capacity) | Unlimited (depends on the drive capacity) | Ubegrenset (avhenger av lagringskapasiteten på disken) | |
| Number of Tracks | 16 | 16 | 16 | ||
| Data Capacity | Approx. 3 MB/Song | Approx. 3 MB/Song | Ca. 3 MB/sang | ||
| Recording Function | Quick Recording, Multi Recording, Step Recording | Quick Recording, Multi Recording, Step Recording | Quick Recording, Multi Recording, Step Recording | ||
| Compatible Data Format | Playback | SMF (Format 0 & 1), XF | SMF (Format 0 & 1), XF | SMF (format 0 & 1), XF | |
| Recording | SMF (Format 0) | SMF (Format 0) | SMF (format 0) | ||
| Multi Pads | Preset | Number of Multi Pad Banks | 507 Banks x 4 Pads | 500 banks x 4 Pads | 349 Banks x 4 pads |
| Audio | Audio Link | Yes | Yes | Ja | |
| Functions | Registration | Number of Buttons | 10 | 8 | 8 |
| Control | Registration Sequence, Freeze | Registration Sequence, Freeze | Registreringssekvens, Freeze | ||
| Playlist | Number of Records | 2,500 (max.) Records per Playlist file | 2,500 (max.) Records per Playlist file | 2 500 (maks.) opptak per spilleliste | |
| Lesson/Guide | Lesson/Guide | Follow Lights, Any Key, Karao-Key, Your Tempo | Follow Lights, Any Key, Karao-Key, Your Tempo | - | |
| Search | Yes | Registration Bank | Registreringsbank | ||
| Demo/Help | Demonstration | Yes | Yes | Ja | |
| Overall Controls | Metronome | Yes | Yes | Ja | |
| Tempo Range | 5 - 500, Tap Tempo | 5 - 500, Tap Tempo | 5-500, Tap Tempo | ||
| Transpose | -12 – 0 – +12 | -12 – 0 – +12 | -12 – 0 – +12 | ||
| Tuning | 414.8 – 440 – 466.8 Hz | 414.8 – 440 – 466.8 Hz | 414.8 – 440 – 466.8 Hz | ||
| Octave Button | Yes | Yes | Ja | ||
| Scale Type | 9 types | 9 types | 9 typer | ||
| Sub Scale Setting | Yes | Yes | Ja | ||
| Bluetooth | Yes (depends on destination) | Yes (depends on destination) | - | ||
| Miscellaneous | Direct Access | Yes | Yes | Ja | |
| Text Display Function | Yes | Yes | Ja | ||
| Wallpaper Customization | Yes | Yes | Ja | ||
| Display Out | HDMI (1,280 × 720p max.) | Yes (by using a USB display adapter. You can check the list on "Downloads" > "Other Downloads"). | - | ||
| Voices | Harmony/Echo | Yes (with Arpeggio) | Yes (with Arpeggio) | Ja (med Arpeggio) | |
| Panel Sustain | Yes | Yes | Ja | ||
| Mono/Poly | Yes | Yes | Ja | ||
| Voice Information | Yes | Yes | Ja | ||
| Styles | Style Creator | Yes | Yes | Ja | |
| OTS Information | Yes | Yes | Ja | ||
| Songs | Score Display Function | Yes | Yes | Ja | |
| Lyrics Display Function | Yes | Yes | Ja | ||
| Song Creator | - | - | - | ||
| Multi Pads | Multi Pad Creator | Yes | Yes | Ja | |
| Audio Recorder/Player | Recording Time (max.) | 80 minutes/Song | 80 minutes/Song | 80 minutter/sang | |
| Recording | WAV (44.1 kHz, 16 bit, stereo) | WAV (44.1 kHz, 16-bit, stereo), MP3 (44.1 kHz, 128/256/320 kbps, stereo) | WAV (44,1 kHz, 16-bit, stereo), MP3 (44,1 kHz, 128/256/320 kbps, stereo) | ||
| Playback | WAV (44.1 kHz, 16 bit, stereo), MP3 (44.1/48.0 kHz, 64/96/128/256/320 kbps or VBR, mono/stereo) | WAV (44.1 kHz, 16-bit, stereo), MP3 (44.1/48.0 kHz, 64–320 kbps and VBR mono/stereo) | WAV (44,1 kHz, 16-bit, stereo), MP3 (44,1/48,0 kHz, 64–320 kbps og VBR, mono/stereo) | ||
| Lyrics Display Function | Yes | - | - | ||
| Time Stretch | Yes | Yes | Ja | ||
| Pitch Shift | Yes | Yes | Ja | ||
| Vocal Cancel | Yes | Yes | Ja | ||
| Storage and Connectivity | Storage | Internal Memory | Yes (approx. 15 GB) | Yes (approx. 4 GB) | Ja (ca. 1 GB) |
| External Drives | USB flash drive | USB flash drive | USB flash drive | ||
| Connectivity | Headphones | Standard stereo phone jack | Standard stereo phone jack | Standard stereojack (stor jackplugg) | |
| FOOT PEDAL | 1 (SUSTAIN), 2 (ART.1), 3 (VOLUME), Function assignable | 1 (SUSTAIN), 2 (ARTICULATION 1), Function assignable | 1 (SUSTAIN), 2 (ARTIKULASJON 1), funksjonstilordnede | ||
| Microphone | Yes (Combo Jack), Phantom Power (+48 V) available | Yes (Microphone/Guitar) | Ja (Mikrofon/gitar) | ||
| MIDI | MIDI A (IN/OUT), MIDI B (IN/OUT) | IN/OUT | INNGANG/UTGANG | ||
| AUX IN | L/L+R, R Standard phone jack | Stereo mini jack | Stereo 3,5 mm mini jack | ||
| LINE OUT | MAIN (L/L+R, R), SUB (1,2), SUB (3,4/AUX OUT) Standard phone jack | MAIN OUTPUT (L/L+R, R), SUB (AUX) OUTPUT (1, 2 (L/L+R, R)) | HOVEDUTGANG (L/L+R, R) | ||
| USB TO DEVICE | Yes (x 3) | Yes (× 2) | Ja | ||
| USB TO HOST | Yes | Yes | Ja | ||
| LAN | Yes (*) Standards: IEEE802.11b/g/n (IEEE802.11n 5 GHz: not compatible), Range of transmit frequency (channels): Models for Europe and Brazil: 2401–2483 MHz (channels 1–13) Others: 2401–2473 MHz (channels 1–11), Maximum RF output power: 14 dBm, Security: WEP, WPA-PSK (TKIP), WPA-PSK (AES), WPA2-PSK (AES), WPA/WPA2 mixed PSK, SAR value: 0.258 W/kg * May not be included, depending on your area. Check with your Yamaha dealer. | - | - | ||
| Amplifiers and Speakers | Amplifiers | - | (15 W+10 W) x2 | 15 W x 2 | |
| Speakers | - | 13 cm x 2 + 2.5 cm (dome) x 2 | 13 cm x 2 + 5 cm x 2 | ||
| Power Supply | Power Supply | AC power cord | PA-300C or an equivalent recommended by Yamaha | PA-300C eller tilsvarende anbefalt av Yamaha | |
| Power Consumption | 37 W | 24 W | 21 W | ||
| Auto Power Off Function | Yes | Yes | Ja | ||
| Accessories | Included Accessories | Owner’s Manual, AC power cord, Music Rest, two Music Rest brackets | Owner's Manual, Music Rest, AC Adaptor (may not be included depending on your area. Check with your Yamaha dealer.) | Brukermanual, musikksupport, AC-adapter (kan være utelatt avhengig av ditt område. Sjekk med din Yamaha-forhandler.) | |
